SHOP FOX Portable W1727 1 HP Dust Collector
SHOP FOX Portable W1727 1 HP Dust Collector
Couldn't load pickup availability
From the manufacturer
Shop Fox W1727 Dust Collector
Built to Last
The Shop Fox W1727 has been specially designed to provide many years of trouble free service. Close attention to detail, ruggedly built parts and a rigid quality control program ensure safe and reliable operation.
Shop Fox W1727 1 HP Dust Collector
2.5 Micron Filtration, 800 CFM
Keep your workshop free of sawdust and improve the air quality with the Shop Fox W1727 dust collector from Woodstock International. Designed for portability, the model W1727 1 HP Dust Collector can be moved from one machine to another when needed, instead of having to build an entire fixed dust collection system and running ducts to each machine.
- This product meets Underwriters Laboratories (UL) 1017-4 and Canadian Standards Association (CSA) C22.2 No. 243-M91 safety standards.
- Air suction capacity: 800 CFM
- Portable base size: 15-3/4 x 39-3/4-inch
Safety Switch with Removable Lockout Key
The W1727 features a safety switch with a removable key to protect against unauthorized use. This Paddle Switch provides a greater degree of safety over other types of 110 volt on/off switches due to its oversize paddle and removable lock-out key. No more fumbling around to locate the off button. Simply slap the paddle down to switch off power.
Compact Design
With an overall height of only 54-1/2 inches with the bags inflated and a portable base with dimensions of 15-3/4 by 39-3/4 inches (W x D), this dust collector is ideal for shops with limited space.
Mobile or stationary
This dust collector can be operated as either a stationary, central dust collector or a mobile unit.
Specifications
- Motor: 1 HP, 110 volts/220 volts, Single-phase
- Aluminum finned TEFC Motor
- Amps: 9 at 110 volts, 4.5 at 220 volts
- Static pressure: 5.67-inches
- Impeller: 9-inch balanced steel, radial fin
- Bag capacity: 2.1 cubic feet
- Bag size (dia. x depth): 14-3/4 x 24-3/8-inch (2)
- Approximate shipping weight: 59 pounds
Easy Fine Filter and Collection Bag Removal
The W1727 lower bag stores 2.1 cubic feet of collected dust in a plastic bag with a quick disconnect bag clamp. To empty the bag simply unlatch the retaining band clamp, remove the lower bag from the dust collector and empty the dust and chips into a garbage can. The upper bag filters wood dust down to 2.5 microns from the collected air, and allows the dust to fall and deposit in the lower dust collection bag.
Features
- Powder coated paint
- Height with bags inflated: 54-1/2-inches
- Handle and casters for portability
- Made in ISO 9001 factory
- Standard bag filtration: 2.5 microns
- 4-inch intake hole
From the brand
Built to Last
The Shop Fox equipment has been specially designed to provide many years of trouble-free service.
Product Description
Designed for portability, the model W1727 1 HP Dust Collector can be moved from one machine to another when needed, instead of having to build an entire fixed dust collection system and running ducts to each machine. CSA certified meeting CSA C22.2 #243-M91 and UL 1017-4th standards.
